Detecting speed： | Max.2200Pcs/Min |
| Machine running Speed： | Max.80M/Min |
| Laminate accuracy： | ±0.5m |
| Label Width： | 20-180mm |
| Label inner Diameter： | φ76mm |
| Label outer Diameter： | Max.φ500mm |
| Function： | RFID Detection and Auto NG Tag Replace |
| Machine Size： | 2830*950*1880（mm） |
| Power： | 220V 50-60Hz 4KW |
| Weight： | 780Kg |
Note: The detection speed is related to the label length, label performance and chip type.
１.High Speed RFID Detection（2200Pcs/min）；
２.CCD Quality Inspection（Taint、Inlay position、Die cut accuracy）；
３.Inkjet mark on the NG Tag，And Auto Remove the bad Tag；
４.Auto Replace the good Tag；
５.With the second station detection，Ensure all the good for output；
６.Can be option Voyantic tagsurance for the perform consistency check；
